Weight | 0.64 lbs |
---|---|
Dimensions | 0.08 × 17 × 11 in |
Plan Format | Digitally Sealed File, Sealed Hardcopy |
Plan Designer | Engineering Express |
Brand | Structall Building Systems, Inc. |
Material | Aluminum, EPS, Glass |
Storefront | Structall, Engineering Express |
3″ Modular Rooms- Glass Wall Gable Room Systems (MPS 20-26259)
Store Home
Read MoreRead Less
Read Disclaimer & Important Information for Use
3″ Modular Rooms- Glass Wall Gable Room Systems (MPS 20-26259)
$100.00 – $300.00 or ( 10 Tokens - 30 Tokens )
This certification is applicable to the Structall 3″ Modular Rooms: Glass Wall Gable Room Systems. It contains numerous dimension, wind speed/pressure, and component options for many common Structall applications. It is sold as an engineered sealed document and meets the requirements of the applicable building code using ASCE 7-10 & ASCE 7-16 for the approval of structural adequacy only. Use it in conjunction with your other approved documents to obtain a building permit.
For states not listed here, please contact us.
The document you are purchasing is a generic performance evaluation. Use of this document for any site-specific application is the responsibility of others. Installations beyond the performance limitations listed within the purchased document, any site-specific designs/certifications, or California-specific projects shall require custom engineering and invalidate the use of this evaluation. Learn more about the use of this document
Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
Sample
Engineering Drawings
