This certification is applicable to AMERICAST Triple Pad 50 x 126 x 4 and is available as a sealed drawing. The certification is sold as an engineered sealed document and meets the requirements of the selected building code above using ASCE 7 for the approval of structural adequacy only, based on the limitations stated, and upon ordering will be signed and sealed by a Professional Engineer of the firm. Use this plan in conjunction with your other approved documents to obtain a permit from the Building Department. Please note: These plans are not certified for Miami Dade County
BRANDS & MODELS FOR PERMIT COVERED WITH THIS PLAN
COMPANY &
MODEL
DIMENSIONS (IN)
WIDTH
LENGTH
HEIGHT
GENERAC/
RG060
38.0
97.4
48.9
GENERAC/
QT070
36.8
96.5
47.9
GENERAC/
QT080
36.8
115.2
54.8
GENERAC/
QT10054
36.8
115.2
54.8
GENERAC/
QT100
36.8
115.2
54.8
GENERAC/
QT13068
36.8
115.2
54.8
GENERAC/
QT130
36.8
115.2
54.8
GENERAC/
QT150
36.8
115.2
54.8
GENERAC/
36.8
115.2
54.8
KOHLER/
150REZGC
44.1
110.2
60.6
Installation variations and site specific drawings outside the scope of this plan can be quoted using our online smart request form by clicking here.
Read MoreRead Less
Read Disclaimer & Important Information for Use
The document you are purchasing is a generic performance evaluation. Use of this document for any site-specific application is the responsibility of others. Installations beyond the performance limitations listed within the purchased document, any site-specific designs/certifications, or California-specific projects shall require custom engineering and invalidate the use of this evaluation. Learn more about the use of this document
Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
