Flush Mounted Channel Sign – Master Plan Sheet (MPS 20-35461)

Flush Mounted Channel Sign – Master Plan Sheet (MPS 20-35461)

$50.00 or ( 5 Tokens )

This Master Plan Sheet (MPS) certifies ALL attachment methods for Non-Illuminated or Illuminated Channel Signs up to 60 feet in elevation, maximum roof heights of 60 feet, and individual sign sizes of up to 200 sf, using your choice of (9) different attachment types. Upon ordering, this document will be signed and sealed by a Professional Engineer.

Use it along with your other project documents to obtain a building permit. This plan is for more generic and installation.

For projects beyond the limitations of this plan, request a custom quote for more detailed site specific project requests by clicking here by using our smart order system. For variations of this plan, click here – select ‘Revision To One Of Our Projects’ when asked, & reference the MPS SKU number listed herein.

This certification is generic and installations beyond this scope, site-specific, or California applications shall require custom engineering that can be performed by Engineering Express. Click here to request a quote.
This field can't be Empty
This field can't be Empty
Show Favorites View Sample
Note: Effective June 1, 2021 licensing fees are added to all calculator and plan orders

Product Documents

Weight0.04 lbs
Dimensions0.0100 × 17.0000 × 11.0000 in

Aluminum, Concrete, Glass, Wood

Plan Designer

Engineering Express

Plan Format

Digitally Sealed File, Sealed Hardcopy

Type of Channel Sign

Illuminated, Non-Illuminated
