Weight | 0.04 lbs |
---|---|
Dimensions | 0.0100 × 17.0000 × 11.0000 in |
Plan Format | Digitally Sealed File, Sealed Hardcopy |
Plan Type | Master Plan Sheet – MPS |
Material | Aluminum |
Plan Designer | Engineering Express |
Type | Large Residential and Commercial, Residential |
Mechanical Aluminum Fence and Gate Performance Evaluation
Mechanical Aluminum Fence and Gate Performance Evaluation
$150.00 – $250.00 or ( 15 Tokens - 25 Tokens )
This design plan is a general performance evaluation for the construction of a six foot high mechanically connected aluminum fence with single or double gates. The plan contains multiple picket options with posts to concrete using surface mount or embedded posts or to soil using economical footing sizes. It has been designed to meet the requirements of current Building Codes and upon ordering will be signed and sealed by a Professional Engineer of the firm. Use it along with your other project documents to obtain a building permit.
For residential Applications (up to 250′) please select the Residential Dropdown. For large Residential or Commercial Applications (up to 500′) please select the Large Residential / Commercial Dropdown.
The plan is generic and not for any site-specific address. Installations beyond the scope and limitations of this document shall require site-specific engineering by a design professional.
For site-specific projects or California applications, click here to apply for membership and request a quote (contractors & manufacturers only, no homeowners for site-specific work by this firm).
