ALLIED AIR: AIREASE SPLIT SYSTEM UNITS (TER 20-32193)


ALLIED AIR: AIREASE SPLIT SYSTEM UNITS (TER 20-32193)

$30.00$50.00 or ( 3 Tokens - 5 Tokens )

This certification is applicable to the Allied Air AirEase Split System Units. The certification is sold as an engineered sealed Evaluation Report and meets the requirements of the structural wind integrity per the selected building code above using ASCE 7-10 & ASCE 7-16 for the approval of unit housing and tie-down clip capacities, and upon ordering will be signed and sealed by a Professional Engineer of the firm. Use it in conjunction with your other approved documents to obtain a building permit.

This certification is generic and installations beyond this scope or site specific applications shall require custom engineering that can be performed by Engineering Express. Click here to request a quote.

Models included in this TER:

Model Number Coil Protection Unit
Width
(in)
Unit
Depth
(in)
Unit
Height
(in)
4SCU14LB118P Louver 26.75 24.75 29.75
4SCU16LE118P
4SHP16LS124P Louver 26.75 24.75 33.75
4SCU14LB124P



Louver





31.25





29.38





29.75

4SCU16LE124P
4SCU14LB136P
4SCU16LE136P
4SCU16LE142P
4SCU16LS136P
4SCU16LE142P



Louver





31.25





29.38





33.75

4SCU16LE147P
4SHP16LE124P
4SHP16LE130P
4SHP14LB136P
4SHP15LE136P
4SCU16LE141P











Louver













31.25













29.38













37.75

4SCU14LB130P
4SCU16LE130P
4SCU16LE142P
4SCU16LE148P
4SCU14LB142P
4SCU14LB148P
4SCU16LS148P
4SHP14LB118P
4SHP14LB124P
4SHP14LB130P
4SHP15LE118P
4SHP15LE124P
4SHP15LE130P
4SHP16LS136P
4SHP16LE118P Louver 31.25 29.38 43.75
4SCU16LS124P
4SHP16LE136P Louver 37.75 35.75 33.75
4SHP14LB142P







Louver









37.75









35.75









37.75

4SHP14LB148P
4SHP15LE142P
4SHP15LE148P
4SHP16LS148P
4SHP20LX124P
4SHP20LX136P
4SCU20LX124P
4SCU20LX136P
4SHP14LB160P











Louver













37.75













35.75













43.75

4SHP15LE160P
4SCU16LE159P
4SCU16LE160P
4SCU14LB160P
4SHP16LE142P
4SHP16LE148P
4SHP16LE160P
4SHP16LS160P
4SCU16LS160P
4SHP20LX148P
4SHP20LX160P
4SCU20LX148P
4SCU20LX160P

What is a TER and how is it used for permitting?

What’s the difference between a TER and a Miami Dade NOA or FL Product Approval?

What do I do if a TER isn’t enough for a permit?

What Doesn’t a TER Do?

For variations of this plan, click here – select ‘Revision To One Of Our Projects’ when asked, & reference the MPS SKU number listed herein.
