Chain Link Fence & Gate Master Plan Sheet (MPS 20-34771)
$150.00 – $250.00 or ( 15 Tokens - 25 Tokens )
This fence master plan certifies up to a 12′ high chain link fence with various gate, post & footer options.This document has been designed to meet the requirements of the selected Building Code and upon ordering will be signed and sealed by a Professional Engineer of the firm. Use it along with your other project documents to obtain a building permit. It is generic and installations beyond the scope and limitations of this document shall require site-specific engineering.
Residential Applications (up to 250′) please select the Residential Dropdown. Large Residential or Commercial Applications (up to 500′) please select the Large Residential / Commercial Dropdown.
This engineer-sealed plan has been designed to meet the requirements of the selected Building Code across the US as well as inside and outside the HVHZin Florida (All of Florida including Dade & Broward Counties). Use it along with your other project documents to obtain a building permit.
For site specific projects,click hereto request a quote.
The document you are purchasing is a generic performance evaluation. Use of this document for any site-specific application is the responsibility of others. Installations beyond the performance limitations listed within the purchased document, any site-specific designs/certifications, or California-specific projects shall require custom engineering and invalidate the use of this evaluation. Learn more about the use of this document
Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
