Cooper & Hunter – Tie-Down To AC Stand, Wall Bracket, Or Concrete.

$60.00$80.00 or ( 6 Tokens - 8 Tokens )

This document is sold as an engineer-certified report for Cooper & Hunter – Tie-Down To AC Stand, Wall Bracket, Or Concrete Performance Evaluation Report and is available as a sealed drawing. The document meets the requirements of the structural wind integrity per the selected building code above using ASCE 7 for the structural approval of unit housing and tie-down clip capacities. This report will be signed and sealed by a Professional Engineer of the firm when purchased and delivered to you via email (using the digital seal method, within 24 hours) or mail (UPS Ground for printed and signed hardcopies, next day in South Florida). Use it with your site-specific documents to obtain a building permit. (Former #20-23255)

Digitally certified documents are licensed to the provided contractor and zip code up to the time frame listed. For extensions beyond that date, you can use the Online Chat to request an extension.

Installation variations and site-specific drawings outside the scope of this plan can be quoted using our online smart request form by clicking here.

Please note: These plans are certified for Florida ONLY.

This product can be used with the following:

MODEL NO. WEIGHT (LBS) WIDTH (in) DEPTH (in) HEIGHT (in) E (in) F (in)
CH-09SPH-xxx 64 30.3 11.8 21.9 11.7 19.2
CH-12SPH-xxx 82 31.5 13.1 21.8 13.4 20.2
CH-18SPH-230 101 33.3 14.3 27.6 13.8 21.3
CH-24/30/36SPH-230 137 37.2 16.1 31.9 16 25.2
CH18-MSPH 106 33.3 14.3 27.6 13.8 21.3
CH28/36MSPH 150 37.2 16.1 31.9 15.9 26.5
CH48MSPH 224 37.5 16.3 52.5 15.9 25
CH-24/36LCDTU 135 37.2 16.1 31.9 15.9 26.5
CH-48/60LCDTU 217 37.5 16.3 52.5 15.9 25
