Cooper & Hunter – Tie-Down to Pad, AC Stand & Wall Bracket (MPS 20-23255)


Cooper & Hunter – Tie-Down to Pad, AC Stand & Wall Bracket (MPS 20-23255)

$40.00$80.00 or ( 4 Tokens - 8 Tokens )

This certification is applicable to the Cooper & Hunter – Unit Tie-Down to Pad, AC Stand, and Wall Bracket and is available as a sealed drawing. The certification is sold as an engineered sealed document and meets the requirements of the selected building code above using ASCE 7  for the approval of structural adequacy only, based on the limitations stated, and upon ordering will be signed and sealed by a Professional Engineer of the firm. Use this plan in conjunction with your other approved documents to obtain a permit from the Building Department.

Please note: These plans are certified for Florida ONLY.

Installation variations and site-specific drawings outside the scope of this plan can be quoted using our online smart request form by clicking here.

BRANDS & MODELS FOR PERMIT COVERED WITH THIS PLAN

MODEL NO. WEIGHT (LBS) WIDTH (in) DEPTH (in) HEIGHT (in) E (in) F (in)
CH-09SPH-xxx 64 30.3 11.8 21.9 11.7 19.2
CH-12SPH-xxx 82 31.5 13.1 21.8 13.4 20.2
CH-18SPH-230 101 33.3 14.3 27.6 13.8 21.3
CH-24/30/36SPH-230 137 37.2 16.1 31.9 16 25.2
CH18-MSPH 106 33.3 14.3 27.6 13.8 21.3
CH28/36MSPH 150 37.2 16.1 31.9 15.9 26.5
CH48MSPH 224 37.5 16.3 52.5 15.9 25
CH-24/36LCDTU 135 37.2 16.1 31.9 15.9 26.5
CH-48/60LCDTU 217 37.5 16.3 52.5 15.9 25
The document you are purchasing is a generic performance evaluation. Use of this document for any site-specific application is the responsibility of others. Installations beyond the performance limitations listed within the purchased document, any site-specific designs/certifications, or California-specific projects shall require custom engineering and invalidate the use of this evaluation. Learn more about the use of this document

Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
