Use this master plan sheet to determine roof panel clear span lengths for a variety of loading and deflection conditions for permit.
This master plan sheet is a signed and sealed non-site-specific structural plan specifying structural capacities for the indicated product. It contains numerous dimensions, wind speed/pressure, and component options for many common Structall applications. Use this plan in conjunction with your other approved documents to obtain a building permit.
Installation variations, California applications, or site-specific drawings outside the scope of this plan can be quoted using our online smart request form by clicking here.
Contact your Structall representative for more information on this product and the family of Structall systems and components.
The document you are purchasing is a generic performance evaluation. Use of this document for any site-specific application is the responsibility of others. Installations beyond the performance limitations listed within the purchased document, any site-specific designs/certifications, or California-specific projects shall require custom engineering and invalidate the use of this evaluation. Learn more about the use of this document
Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
