Wind Pressure Charts For Garage Doors & Large Openings
$22.50 – $25.00 or ( 2.3 Tokens - 2.5 Tokens )
These charts are sold as engineered sealed documents for the selected Building Code. They assist in determining the required site components & cladding wind pressures to submit for a building permit. By identifying your site design conditions on the applicable chart, the results are then compared to the limiting design pressures of the product being installed to obtain your building permit. Learn more on our design wind page.
CURRENT FLORIDA WIND VELOCITY GUIDELINES:
For residential structures (‘Risk Category II’) in Broward and Palm Beach Counties, the required wind velocity is 170mph.
For residential structures (‘Risk Category II’) in Miami-Dade County, the required wind velocity is 175mph.
If you are near the coast, it’s Exposure ‘D’; inland is Exposure ‘C’.
Additional wind velocity requirements can be verified by contacting your local Building Department or visiting the ATC Wind Site.
| Weight | 0.04 lbs |
|---|---|
| Dimensions | 0.0100 × 17.0000 × 11.0000 in |
| Wind Speed (mph) | 170, 175 |
| Exposure | C, D |
| Plan Type | Wind Pressure Chart |
| Storefront | Engineering Express |
| Material | Glass |
| Plan Format | Digitally Sealed E-Permit File, Raised Sealed Hardcopy |
Click here to request a quote for us to provide these services, which can also be provided by others who would then become responsible for the applicability of this evaluation. Contact Us if there are any questions and always consult with a design professional before using any generic performance evaluations with your project.
